Windows installation failure is usually caused by hardware incompatibility, missing drivers, hard disk problems or damage to the installation media. Solutions include: 1. Check whether the installation media is normal, re-download the ISO file and use official tools to create a boot disk; 2. Clean the hard disk partition, use the diskpart command to clear the residual data and adjust the partition format; 3. Load the motherboard or storage device drivers, turn off the quick boot and secure boot settings; 4. Detect the health of the memory and hard disk, and replace the data cable or slot to troubleshoot hardware failures.

Windows installation has failed This problem is really a headache, especially when the system is urgently needed. There may be many reasons for this error, such as hardware incompatibility, missing drivers, hard disk problems, or damaged installation media. The key is to troubleshoot according to specific error prompts.

Here are some common situations that cause Windows installation to fail and corresponding solutions:

1. Check whether the installation media is normal

If you are using a USB or CD to install the system, first make sure there is no problem with the installation file itself. Sometimes the downloaded ISO file is corrupted or an error occurs when writing to the USB drive, which will cause the installation to fail.

• Re-download the ISO image and use official tools such as Media Creation Tool to create a boot disk
• Use another computer to test whether this USB drive can boot normally
• If it is a CD, check for scratches or dust

If you get stuck in the "load file" stage during the installation process, this is most likely the problem.

2. Hard disk partition or format issues

Sometimes even if you clear the hard drive, the installation may fail due to the wrong partition table format (such as MBR and GPT not matching), or residual data.

Common Situations:

• Using traditional BIOS startup method but using GPT partition hard disk
• There are also EFI partitions or other hidden partitions of the old system on the hard disk

Solution:

• Press Shift F10 on the installation interface to open the command prompt
• Enter the following command to clean the hard drive (operate with caution):
  • diskpart
  • list disk
  • select disk X (X is your system disk number)
  • clean
• Then restart the installation process

If it is a dual-system installation, you should also pay attention to turning off the Quick Boot and Secure Boot settings.

3. Hardware compatibility or driver issues

Some motherboards or peripherals (such as NVMe SSDs, RAID controllers) require specific drivers to allow the installer to recognize the hard disk, otherwise it will be stuck in the steps of "The hard disk cannot be found" or "The device cannot be found".

Solution:

• Check the motherboard model and go to the official website to download the corresponding storage controller driver (usually INF or RAID driver)
• Select "Load Driver" in the installation interface and insert the USB drive with the driver to load manually
• If it is an NVMe SSD, make sure that the NVMe support option is enabled in the BIOS

In addition, some new hardware may not be supported by older versions of Windows, so it is recommended to use the latest system image.

4. Memory or hard disk failure

Hardware problems can also lead to installation failure, especially loose memory sticks or bad hard drives.

You can try:

• Plug and unplug the memory module and use MemTest86 to test memory stability
• Use a hard disk detection tool (such as CrystalDiskInfo) to view hard disk health
• Try replacing the SATA data cable or changing the hard disk slot

If the blue screen is frequently encountered or stuck during installation, it is likely to be caused by hardware problems.

When Windows installation fails, don't rush to try again many times. First check if there is a specific code or prompt word for the error message, so it is easier to locate the problem. The above methods cover most common reasons, and basically these ideas.
