How to configure IIS log rollover by size?
Jul 22, 2025 am 12:18 AMIIS can automatically split logs by file size through registry configuration. 1. Enter the "Log" setting in IIS Manager, check "Enable log rollover based on file size", and uncheck "Schedule". 2. Modify the registry path HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\W3SVC\Parameters, add or modify the MaxFileSize DWORD value (unit bytes), such as 100MB to 104857600. 3. Restart the IIS effective settings and pay attention to setting the file size reasonably to balance performance and management needs. In addition, it is recommended to keep the default naming format, specify independent log paths, and clean the logs regularly.
IIS scrolls logs by day by day by default, but if you want the logs to be automatically divided by file size, for example, when the number of visits per day is particularly large, scrolling by size can avoid too large a single log file, affecting viewing and analysis. This setting is actually not complicated, but many people are not very clear about how to operate it.

Next, I will explain step by step how to configure IIS logs to scroll by size.
Modify the location of the log scroll settings
In IIS Manager, the settings for log scrolling are located in the Log section at the Website or Server level. The specific operations are as follows:

- Open IIS Manager, select the website you want to set up or set it directly on the server node (affects all sites).
- Double-click the Log icon.
- Click "Select Log File Format" in the "Operation" panel on the right.
- Click "Edit Log File Settings".
At this time, a window will pop up with two key options:
- Schedule
- Enable log rollover based on file size
Check "Enable log rollover based on file size", and uncheck "Schedule".

In this way, the logs will no longer scroll by the day, but will create a new log file based on the file size.
Set the maximum log file size
The default maximum log size of IIS is 20MB, but this value can be modified through the registry. Yes, you read that right. It is not set in the IIS management interface, but you need to change the registry.
The specific path is as follows:
HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\W3SVC\Parameters
Add or modify a DWORD value named MaxFileSize
in bytes under this path.
For example, if you want to set it to 100MB, fill in 104857600
(100 1024 1024).
After the modification, you need to restart IIS (you can use the iisreset
command) before the new settings will take effect.
What should be noted is:
- If set too small, it may cause frequent switching of log files, affecting performance
- If set too large, the purpose of "scroll by size" may not be achieved.
- Generally, it is recommended to set between 50MB and 200MB.
Log file naming and path suggestions
IIS uses dates as part of the log file name by default, such as u_ex240405.log
. If you enable Scroll by size, the file name will become a format similar to u_ex240405_0001.log
.
Suggest you:
- Keep the default naming method so that the log files are in order
- Set the log path to a separate disk partition to prevent excessive logs from filling the system disk
- Regularly clean old logs or set up script archives
You can also adjust log behavior by configuring period
and truncSize
properties of logFile
node (in the applicationHost.config
file).
Basically that's it. Although the IIS interface does not support setting the maximum value scrolling by size directly, it is not particularly difficult to modify through the registry. As long as you pay attention to the reasonable restart and size settings, you can control the log file size well.
