An artboard in Photoshop is a movable, resizable container that acts as an individual canvas within a single document. It allows designers to create multiple layouts or design variations side by side, each with its own size and content. Artboards are ideal for web layouts, app screens, banners, and print materials, enabling efficient exporting of each board as a separate file. To use artboards, select the Artboard Tool (Shift O), choose preset or custom sizes, and click-drag to place them on the canvas. They can be renamed in the Layers panel for better organization, and layers are grouped per artboard to keep the workspace clean. Benefits include faster exporting via File > Export > Artboards, improved project organization, easier design comparisons, and clearer handoff to developers. Key tips: Canvas Size affects the entire document, artboards can be rearranged but shouldn’t overlap unintentionally, some tools behave differently across boards, and older Photoshop versions may not support artboards properly.
Artboards in Photoshop are like individual canvases within a single document. Think of them as separate pages or frames where you can design different elements — perfect for creating multiple versions of a layout, designing app screens, or organizing different parts of a project all in one file.

What Exactly Is an Artboard?
An artboard is essentially a movable, resizable container that holds your design content. Unlike traditional Photoshop documents where everything lives on a single canvas, artboards let you have multiple isolated workspaces side by side. They’re especially useful when working on web layouts, mobile designs, banners, or print materials that need to be exported separately.

You can create as many artboards as you want in a document and arrange them horizontally or vertically. Each one can have its own size and content, and when you export, you can choose to export each artboard as its own file automatically — which saves a lot of time compared to manually saving each version.
How Do You Create and Use Artboards?
To start using artboards:

- Choose the Artboard Tool (Shift O), or select it from the toolbar under the Move Tool.
- In the options bar at the top, you can choose from preset sizes (like common phone or tablet dimensions) or set custom width and height.
- Click and drag to place your first artboard on the canvas.
Once you've got more than one, you can rename them in the Layers panel for better organization. This makes it easier to keep track if you're working on several variations or screens.
Also, layers are grouped per artboard, so when you select an artboard, only its related content shows up — helping keep things clean and focused.
Why Are Artboards Useful?
They bring a few key benefits that make life easier:
- Efficient exporting: Export each artboard as a separate file with one command (File > Export > Artboards).
- Better organization: Keep multiple designs together without opening multiple files.
- Design variations: Try out different color schemes, layouts, or UI elements side by side.
- Handoff clarity: When handing off to developers, clearly labeled artboards help explain how each screen or component should look.
This makes them especially popular among UI/UX designers and anyone doing multi-page or multi-device design work.
A Few Tips to Keep in Mind
Here are a few small but important things to remember when working with artboards:
- If you use the Canvas Size option, it affects the entire document, not just one artboard.
- You can rearrange artboards by dragging them around — just make sure they don’t overlap unless you want them to share space.
- Some features like Content-Aware Fill or Auto-Select behave differently across artboards, so double-check how selections work.
- If you’re sharing your file with someone who uses an older version of Photoshop, artboards might flatten into layers — always confirm compatibility.
Using artboards takes a little getting used to if you’ve been working with standard documents all along, but once you do, it’s hard to go back. It’s a simple feature that brings a lot of flexibility and efficiency — especially if you're designing for digital platforms.
The above is the detailed content of What are artboards in Photoshop. For more information, please follow other related articles on the PHP Chinese website!
