MySQL Enterprise Firewall is an application-layer whitelisting mechanism used in MySQL Enterprise Edition to enhance database security. It supports three modes and is managed through the SQL interface. 1. It filters SQL queries through predefined rules to prevent attacks such as SQL injection, and is only available for enterprise version. 2. Configuration includes enabling plug-ins, creating rule groups, and loading rules. Pay attention to regular syntax and rule conflicts. 3. Common application scenarios include preventing SQL injection, controlling third-party access and audit monitoring. It is recommended to use it in combination with other security measures. 4. When using it, you need to pay attention to performance impact, ORM tool compatibility and rule update frequency, and master the skills of viewing rules and log control. Rational configuration can improve security, but it needs to be flexibly used to meet actual business needs.
MySQL Enterprise Firewall is a security feature provided by MySQL to enhance database access control. It is not a network firewall in the traditional sense, but a "whitelist" mechanism at the application layer, used to limit which SQL statements can be executed, thereby preventing attacks such as SQL injection.

Let’s take a look at its functions and usage suggestions from several practical perspectives.
1. What is MySQL Enterprise Firewall?
Simply put, it is a plug-in that runs inside MySQL Server and filters SQL queries through predefined rules. These rules can be set based on user, host, or query content. When a user executes SQL, if the statement does not meet the user's "whitelist", it will be intercepted.

- It is part of the Enterprise Edition MySQL, and the Community Edition does not include this feature.
- Three modes are supported: protection mode (recording illegal queries), recording mode (recording only but not stopping) and clear mode (returning rules).
- It can be managed through the SQL interface, such as adding rules, enabling/disabling policies, etc.
2. How to configure and use it?
Configuring MySQL Enterprise Firewall mainly includes the following steps:
-
Enable plugins:
INSTALL PLUGIN mysql_firewall SONAME 'mysql_firewall.so';
Create a rule group (by user):
INSERT INTO mysql.firewall_whitelist (USER, HOST, RULE) VALUES ('app_user', '192.168.1.%', '^SELECT.*');
Loading rules take effect:
CALL mysql.sp_reload_firewall_rules();
A few points to note:
- Rules use regular expressions, be careful about syntax accuracy when writing, otherwise it may mistakenly block legal statements.
- It is recommended to debug the rules in the test environment first and then go online.
- Each user host combination corresponds to a list of rules, so be careful about rule conflicts or overwriting issues.
3. Practical application scenarios and suggestions
Common usage scenarios include:
- Prevent SQL injection: Restrict application users to execute only specific types of statements such as
SELECT
andUPDATE
, and prohibitDROP
orDELETE
. - Control access to third-party tools: For example, the reporting system can only perform query operations and cannot modify data.
- Audit and monitoring: Check through logs which statements are intercepted and discover potential security risks.
Recommended usage:
- In the early stage, you can use the "record mode" to observe the traffic, confirm that the rules will not affect normal services and then switch to "protected mode".
- Don't enable complex rules for all users, as maintenance costs can be high.
- Use it in conjunction with other security measures, such as account permission control, SSL connection, etc. Don’t expect the firewall to ensure security alone.
4. Frequently Asked Questions and Precautions
- Performance impact : Generally speaking, the impact is not large, but if there are too many rules or the regularity is too complicated, it may slow down the query processing speed.
- Compatibility issues : SQL generated by some ORM tools is relatively dynamic and easily triggers firewall interception.
- Rule update frequency : If business changes frequently, firewall rules need to be updated regularly, otherwise mistakenly blocked will be prone to occur.
Some tips:
- Use
SHOW CREATE FIREWALL RULES FOR user@host
to view the current rule. - Log output can be controlled through system variables, such as setting
mysql_firewall_mode
toRECORDING
. - If the rule error causes the login to be unable to log in, you can temporarily disable the plug-in to resume access.
Basically that's it. MySQL Enterprise Firewall is a practical but easily overlooked feature, suitable for use in production environments with high security requirements. Rational configuration can effectively improve the database security level, but it also needs to be flexibly used in light of actual conditions.
