This example shows the implementation of state mode in C. 1. Define the State interface class and declare pure virtual functions of play, pause, and stop; 2. Implement the three specific state classes StoppedState, PlayingState, and PausedState, each defining behavior based on the current state; 3. Create an AudioPlayer context class, hold the current state object and delegate the state behavior; 4. Call the play, pause, and stop methods in the main function, and the behavior changes with the internal state change; the final output conforms to the expected state transition, and the state mode is fully implemented to eliminate conditional logic and improve maintainability.

The State Pattern is a behavioral design pattern that allows an object to change its behavior when its internal state changes. In C , this is typically implemented using polymorphism — each state is represented by a separate class, and the context object delegates state-specific behavior to the current state object.

Here's a practical C example of the State Pattern:

? Example: A Simple Audio Player

Imagine an audio player that can be in different states: Stopped , Playing , or Paused . The behavior of actions like play() , pause() , and stop() depends on the current state.

? Step 1: Define the State Interface

 // State.h
#ifndef STATE_H
#define STATE_H

class AudioPlayer; // Forward declaration

class State {
public:
    virtual ~State() = default;
    virtual void play(AudioPlayer* player) = 0;
    virtual void pause(AudioPlayer* player) = 0;
    virtual void stop(AudioPlayer* player) = 0;
};

#endif

? Step 2: Implement Concrete States

 // StoppedState.h
#ifndef STOPPED_STATE_H
#define STOPPED_STATE_H

#include "State.h"

class StoppedState : public State {
public:
    void play(AudioPlayer* player) override;
    void pause(AudioPlayer* player) override;
    void stop(AudioPlayer* player) override;
};

#endif

 // StoppedState.cpp
#include "StoppedState.h"
#include "AudioPlayer.h"
#include <iostream>

void StoppedState::play(AudioPlayer* player) {
    std::cout << "Starting playback.\n";
    player->changeState(new PlayingState());
}

void StoppedState::pause(AudioPlayer* player) {
    std::cout << "Can&#39;t pause — already stopped.\n";
}

void StoppedState::stop(AudioPlayer* player) {
    std::cout << "Already stopped.\n";
}

 // PlayingState.h
#ifndef PLAYING_STATE_H
#define PLAYING_STATE_H

#include "State.h"

class PlayingState : public State {
public:
    void play(AudioPlayer* player) override;
    void pause(AudioPlayer* player) override;
    void stop(AudioPlayer* player) override;
};

#endif

 // PlayingState.cpp
#include "PlayingState.h"
#include "AudioPlayer.h"
#include <iostream>

void PlayingState::play(AudioPlayer* player) {
    std::cout << "Already playing.\n";
}

void PlayingState::pause(AudioPlayer* player) {
    std::cout << "Pausing playback.\n";
    player->changeState(new PausedState());
}

void PlayingState::stop(AudioPlayer* player) {
    std::cout << "Stopping playback.\n";
    player->changeState(new StoppedState());
}

 // PausedState.h
#ifndef PAUSED_STATE_H
#define PAUSED_STATE_H

#include "State.h"

class PausedState : public State {
public:
    void play(AudioPlayer* player) override;
    void pause(AudioPlayer* player) override;
    void stop(AudioPlayer* player) override;
};

#endif

 // PausedState.cpp
#include "PausedState.h"
#include "AudioPlayer.h"
#include <iostream>

void PausedState::play(AudioPlayer* player) {
    std::cout << "Resuming playback.\n";
    player->changeState(new PlayingState());
}

void PausedState::pause(AudioPlayer* player) {
    std::cout << "Already paused.\n";
}

void PausedState::stop(AudioPlayer* player) {
    std::cout << "Stopping playback.\n";
    player->changeState(new StoppedState());
}

? Step 3: Context Class (AudioPlayer)

 // AudioPlayer.h
#ifndef AUDIO_PLAYER_H
#define AUDIO_PLAYER_H

#include "State.h"

class AudioPlayer {
private:
    State* currentState;

    // Helper to delete old state
    void changeState(State* newState) {
        delete currentState;
        currentState = newState;
    }

public:
    AudioPlayer();
    ~AudioPlayer();

    void play();
    void pause();
    void stop();

    // For testing: get current state type (optional)
    std::string getStateName() const;
};

#endif

 // AudioPlayer.cpp
#include "AudioPlayer.h"
#include "StoppedState.h"
#include <typeinfo>

AudioPlayer::AudioPlayer() {
    currentState = new StoppedState(); // Initial state
}

AudioPlayer::~AudioPlayer() {
    delete currentState;
}

void AudioPlayer::play() {
    currentState->play(this);
}

void AudioPlayer::pause() {
    currentState->pause(this);
}

void AudioPlayer::stop() {
    currentState->stop(this);
}

std::string AudioPlayer::getStateName() const {
    if (dynamic_cast<const StoppedState*>(currentState))
        return "Stopped";
    else if (dynamic_cast<const PlayingState*>(currentState))
        return "Playing";
    else if (dynamic_cast<const PausedState*>(currentState))
        return "Paused";
    return "Unknown";
}

? Step 4: Usage Example

 // main.cpp
#include "AudioPlayer.h"
#include <iostream>

int main() {
    AudioPlayer player;

    player.play(); // Output: Starting playback.
    player.pause(); // Output: Pausing playback.
    player.play(); // Output: Resuming playback.
    player.stop(); // Output: Stopping playback.
    player.pause(); // Output: Can&#39;t pause — already stopped.

    return 0;
}

? Output

 Starting playback.
Pausing playback.
Resuming playback.
Stopping playback.
Can't pause — already stopped.

? Key Points

• The context ( AudioPlayer ) delegates state-specific behavior to the current State object.
• Each concrete state handles transitions and behavior independently.
• The changeState() method safely deletes the old state and switches to a new one.
• You avoid messy if/else or switch statements based on state variables.

?? Notes

• This example uses raw points and new/delete . In production, consider using smart points (eg, std::unique_ptr ) for better memory safety.
• The AudioPlayer owns its state, so it handles deletion properly.
• States are created on the heap — fine for small examples, but pooling or flyweight patterns can optimize in performance-critical cases.

That's a clean, working C implementation of the State Pattern . It's especially useful when you have complex state-dependent logic that would otherwise become unmanageable with conditions.

Basically just organize your states, let them handle their own rules, and let the context delegate.
