Ensure you have a working phone line, a dial-up modem (built-in or USB), and a phone cable. 2. Open Settings, go to Network & Internet > Dial-up, click Set up a new connection or network, then select Connect to the Internet and choose Set up a new connection anyway. 3. Select Dial-up, enter the ISP-provided phone number, name the connection, optionally input username and password, and click Connect. 4. To connect, go to Settings > Network & Internet > Dial-up, select your connection, and click Connect, entering credentials if prompted. 5. For issues like error 630, ensure no other program uses the modem; verify the phone number and connection port; adjust modem speaker settings via Device Manager; save login details in connection Properties. To create a desktop shortcut, make a new shortcut with the command rasdial "Connection Name" "Username" "Password", customizing with actual details, then use it for quick access. Setting up dial-up in modern Windows is simple with the right hardware and ISP information, offering a functional, albeit slow, internet option when needed.

Setting up a dial-up connection in Windows might seem outdated, but it's still useful in areas with limited internet access or for connecting to certain legacy systems. Here’s how to set it up in modern versions of Windows (10 and 11), step by step.

1. Check Your Hardware and Phone Line

Before starting, make sure you have:

• A working phone line with active service.
• A dial-up modem — most older computers have one built-in, but if yours doesn’t, you can use a USB external modem.
• A phone cable to connect the modem to the wall jack.

? Tip: If you're using a laptop without a built-in modem, you’ll need a compatible external USB dial-up modem.

2. Open the Network Setup Wizard

1. Press Windows I to open Settings.
2. Go to Network & Internet > Dial-up (in Windows 10, you may need to click “Change adapter options” first).
3. Click Set up a new connection or network.
4. Select Connect to the Internet, then click Next.
5. Choose Set up a new connection anyway.

3. Create the Dial-Up Connection

1. Select Dial-up.
2. In the "Dial-up phone number" field, enter the access number provided by your ISP (Internet Service Provider).
   Example: 555-1234 (this varies by location and provider).
3. Enter a connection name (e.g., “My Dial-Up Connection”).
4. Optionally, enter the username and password if your ISP requires them.
5. Check "Make this the default connection" if you want Windows to use it automatically.
6. Click Connect.

? Note: You can leave username and password blank and enter them later when connecting.

4. Connect to the Dial-Up Network

1. Go to Settings > Network & Internet > Dial-up.
2. Click on your saved connection.
3. Click Connect.
4. If prompted, enter your username and password.
5. Wait while the modem dials and establishes the connection.

You’ll hear the classic handshake sound if your modem has a speaker enabled.

5. Troubleshooting Tips

• Error 630 or "Port not available"? Make sure no other program is using the modem.
• Can’t connect? Double-check the phone number, and ensure the phone line is plugged into the correct line-in port on the modem.
• No sound from modem? Some modems have a speaker setting — check modem properties in Device Manager.
• Need to save login details? Right-click the connection > Properties > Options > check "Remember my password".

Bonus: Create a Desktop Shortcut

1. Right-click the desktop > New > Shortcut.
2. Type:

   rasdial "Your Connection Name" "Username" "Password"

   (Replace with actual values; omit password if you prefer to enter it manually.)

3. Name it (e.g., “Dial-Up Connect”) and finish.

Now you can double-click to connect quickly.

Basically, setting up dial-up in Windows is straightforward if you have the right hardware and ISP details. It’s slow by today’s standards, but it still works when nothing else is available.
