How to deploy and use PMM to monitor MySQL? 1. Install PMM Server: Pull the image through Docker and run the container, map ports 80 and 443, and access the web page initialization configuration; 2. Access MySQL instance: Install PMM Client on the target server, register with Server and add MySQL monitoring to ensure that MySQL users have PROCESS, REPLICATION CLIENT and other permissions; 3. Frequently asked questions: The page loads slowly, the Prometheus collection frequency can be adjusted, and the client's running status needs to be checked if the data is not updated. The verification test can be temporarily closed if the SSL error occurs. The retention period can be extended through remote storage. It is recommended to deploy independent PMM instances for different environments to improve management efficiency.
MySQL monitoring has always been a pain point, especially when the production environment has large data volume and many instances. As an open source database performance monitoring tool, PMM (Percona Monitoring and Management) can indeed solve many problems. If you are also considering deploying a reliable MySQL monitoring system, PMM is a good choice.

The following is a few key points to talk about what needs to be paid attention to during the deployment and use of PMM.
How to install and deploy PMM Server?
PMM Server is the visual core of the entire monitoring system, which collects data and presents Dashboard. The current mainstream deployment method is to use Docker to install, which is simple and convenient.

The steps are roughly as follows:
- Make sure your server has Docker installed
- Execute the command to pull the image and run the container:
docker run -d -p 80:80 -p 443:443 --name pmm-server percona/pmm-server:latest
- Visit
http://<服務器IP>
to enter the web page. The default account password is admin/admin
Note: If you want to use HTTPS, it is recommended to configure the certificate in advance, or use the reverse proxy to achieve encrypted access.

How to connect MySQL instance to PMM?
The PMM Client is deployed on the monitored database server to collect metrics and send them to the PMM Server.
Specific operation procedures:
- Install the PMM Client on the target machine:
wget https://www.percona.com/downloads/pm-client/LATEST/binary/redhat/7/x86_64/percona-pm-client-*.noarch.rpm yum install -y percona-pm-client-*.noarch.rpm
- Register a client to Server:
pmm-admin config --server <PMM_SERVER_IP>
- Add MySQL instance monitoring:
pm-admin add mysql --user=root --password=your_password
This allows you to see the monitoring information of the instance on the PMM web page.
One thing that is easy to ignore is to ensure that MySQL users have permission to execute SQL queries required for monitoring, such as PROCESS
, REPLICATION CLIENT
, etc., otherwise some metrics may not be obtained.
PMM FAQs and Optimization Suggestions
When you first use PMM, you may encounter some small pitfalls. Here are a few common situations and solutions:
- Page loading slow : It may be because of insufficient server resources or too many database connections. It is recommended to adjust the collection frequency of Prometheus appropriately.
- Data is not updated : Check whether the client is running normally, you can use
systemctl status pmm-client
to view the status. - SSL error : If SSL check is enabled but the certificate is not configured correctly, the connection will fail. You can temporarily close SSL to verify that the test is related to this.
- Historical data loss : PMM retains data for 30 days by default. If storage is required for longer, remote storage needs to be configured separately (such as Thanos or VictoriaMetrics).
In addition, if you have multiple environments (development, testing, production), you can deploy an independent PMM instance for each environment to avoid data being mixed together to affect analysis efficiency.
Basically that's it. PMM is powerful, but it is not complicated to deploy. The key is to understand its structure and the role of each component. As long as you follow the steps step by step, there will generally be no major problems.
The above is the detailed content of MySQL PMM (Percona Monitoring and Management) Setup. For more information, please follow other related articles on the PHP Chinese website!
