Implementing MySQL Point-in-Time Recovery on Cloud Platforms
Jul 27, 2025 am 02:26 AMMySQL's real-time point recovery (PITR) is implemented through binary logs (binlog) on the cloud platform. 1. It is necessary to confirm that binlog is enabled and set to ROW format, and the retention period is adjusted according to needs; 2. Perform full backups regularly, such as using mysqldump, file snapshots or XtraBackup, and record the binlog location; 3. Obtain the binlog for the corresponding time period from the cloud platform during recovery, use mysqlbinlog to parse and apply it to the database; 4. It is recommended to combine automation tools and monitoring mechanisms to ensure the smooth execution of PITR.
The real-time point recovery (PITR) of MySQL on the cloud platform is mainly accomplished through binary logs (binlog). It allows you to restore your database to a specific point in time instead of just relying on full backups. This is very useful for scenarios such as misoperation and data corruption.

1. Confirm to enable and configure the binary log
All binlog-based recovery depends on whether it is enabled and retention policies. On cloud platforms, it is usually turned on by default, but you still need to check and confirm:
- Check whether it is on : Execute
SHOW VARIABLES LIKE 'log_bin';
If ON is returned, it means it is enabled. - View binlog format : Run
SHOW VARIABLES LIKE 'binlog_format';
ROW mode is recommended because it records actual data changes and is more reliable than STATEMENT. - Retention cycle settings : In hosting services such as AWS RDS or Alibaba Cloud, the number of retention days of binlog can be adjusted through parameter groups. The default may be 1 day, which is appropriately extended as needed.
If you are using a fully managed MySQL service, such as Google Cloud SQL or Tencent Cloud CDB, some settings may not support direct modification and need to adjust relevant parameters in the console.

2. Regularly make basic backups (full backups)
PITR does not work alone, it requires a benchmark point - full backup. You can use one of the following methods for basic backup:
- Use
mysqldump
for logical backup, add--single-transaction
parameters to ensure consistency - Use file system snapshots (such as LVM or cloud platform snapshots)
- Use Percona XtraBackup for physical backup, suitable for large databases
For example, on EC2, you can use EBS snapshots to make a complete backup and record the current binlog location:

mysql -e "FLUSH TABLES WITH READ LOCK;" mysqldump --single-transaction --master-data=2 > backup.sql mysql -e "UNLOCK TABLES;"
Then record backup.sql
and the binlog file name/location at that time for subsequent recovery.
3. The binlog required to be used when preparing for recovery
Most cloud platforms automatically archive binlogs, but you need to know how to get them:
- In AWS RDS, you can use the
mysqlbinlog
tool to remotely pull binlog for a specified time period - Alibaba Cloud and Huawei Cloud usually provide the function of downloading binlog, or exporting through the DMS platform.
- Self-built MySQL instance can directly access binlog files on the server
The recovery process is roughly as follows:
- Restore full backups to temporary instances or test environments
- Find the binlog content after the end time of the full backup
- Use
mysqlbinlog
to parse and apply these binlogs to the target database
For example:
mysqlbinlog --start-datetime="2024-01-01 10:00:00" \ --stop-datetime="2024-01-01 12:00:00" \ binlog.000001 | mysql -u root -p
This way, all changes during this period can be played back, thereby achieving the goal of "recovering to a certain point in time".
IV. Automation and monitoring suggestions
To ensure that PITR can be executed smoothly, it is best to combine some automation tools and monitoring mechanisms:
- Regularly check whether the binlog is turned on and whether the format is correct
- Monitor whether the binlog retention time is sufficient to cover business needs
- Add binlog location records to automated backup scripts
- Set alarms and promptly notify binlog when deletion is too early or backup fails
You can create timed tasks (such as AWS Lambda EventBridge) in the cloud platform, regularly pull binlog status information and store it for quick recovery.
Basically that's it. The whole process is not complicated, but details are easy to ignore, such as binlog format and backup time point failure. If you are not careful, you may cause recovery failure.
