This CSS Grid example shows how to use grid layout to create a web page structure containing the header, sidebar, main content area and bottom. 1. Enable grid layout through display: grid; 2. Use grid-template-areas to name the area and define a layout structure with three rows and two columns; 3. grid-template-columns set the left fixed 200px and the right adaptive; 4. grid-template-rows define the head 60px, main content adaptive, and bottom 50px; 5. Set the gap attribute to set the 10px spacing; 6. min-height: 100vh to ensure the container is full of viewport; 7. Responsive design changes to a single-column layout when the screen width is less than 600px through media query, and displays the head, main content, sidebar and bottom in turn to achieve mobile adaptation, fully covering core functions such as grid containers, area naming, fr units, spacing control and responsive layout.
A typical CSS Grid layout example can help you quickly understand how to use a grid system to build modern web layouts. Here is a practical, clear CSS Grid example that implements a common "home layout": including the header, sidebar, main content area, and bottom.
Basic HTML structure
<div class="container"> <header class="header">Header</header> <aside class="sidebar">Sidebar</aside> <main class="main">Main Content</main> <footer class="footer">Footer</footer> </div>
CSS Grid Styles
.container {
display: grid;
/* Define the rows and columns of the grid*/
grid-template-columns: 200px 1fr; /* 200px on the left, adaptive on the right*/
grid-template-rows: 60px 1fr 50px; /* head 60px, main content adaptive, bottom 50px */
/* Define grid area naming layout*/
grid-template-areas:
"header header"
"sidebar main"
"footer footer";
/* Grid spacing*/
gap: 10px;
/* The minimum height of the page is full of viewport*/
min-height: 100vh;
font-size: 18px;
font-family: Arial, sans-serif;
}
.header {
grid-area: header;
background-color: #4CAF50;
color: white;
display: flex;
align-items: center;
justify-content: center;
}
.sidebar {
grid-area: sidebar;
background-color: #f4f4f4;
padding: 20px;
}
.main {
grid-area: main;
background-color: #e0e0e0;
padding: 20px;
}
.footer {
grid-area: footer;
background-color: #333;
color: white;
display: flex;
align-items: center;
justify-content: center;
}Key points description
1. grid-template-areas naming layout
- Use
grid-areawithgrid-template-areasto visually define the layout structure, which is very intuitive. - Each line of string represents a line of the grid, and each word represents a region.
2. grid-template-columns and grid-template-rows
-
200px 1fr: The first column has a fixed width, and the second column occupies the remaining space. -
1frmeans "a free space", suitable for responsive design.
gap attributes
- Set the spacing between grid items, replacing complex margin calculations.
4. min-height: 100vh
- Let the container reach at least the entire viewport height to avoid the layout collapse when there is little content.
Extension: Responsive adjustment (mobile adaptation)
You can use media query to change to a single column layout on the small screen:
@media (max-width: 600px) {
.container {
grid-template-columns: 1fr;
grid-template-areas:
"header"
"main"
"sidebar"
"footer";
}
}In this way, the content will be arranged in order on the mobile phone, making it easier to read.
This example covers the core usage of CSS Grid:
- Grid container settings
- Regional naming
- Elastic unit
fr - Spacing control
- Responsive compatibility
Basically all that is, not complicated but practical enough.
