Difference between `grid-template-columns` and `grid-auto-columns`?
Jul 22, 2025 am 02:09 AM
The core difference is that grid-template-columns defines explicitly set columns in the layout, while grid-auto-columns controls implicitly created columns when needed. grid-template-columns sets up the exact number and size of columns you define, such as 200px, 1fr, 2fr, creating a fixed structure. If items are placed beyond these defined columns, the browser creates new ones automatically, and grid-auto-columns determines their width. For example, with grid-template-columns: repeat(3, 100px) and grid-auto-columns: 50px, any overflow item placed in column 4 or beyond will fit into newly generated columns of 50px width. Use grid-template-columns to design intentional layouts with known dimensions, and use grid-auto-columns to manage unexpected or dynamic content overflow consistently.
When working with CSS Grid, grid-template-columns and grid-auto-columns both define column sizes, but they target different parts of the grid and behave differently under various conditions.
What’s the core difference?
In short:
-
grid-template-columnsdefines the number and size of columns that you explicitly create. -
grid-auto-columnssets the size for columns that are created implicitly when there are more grid items than defined tracks.
Now let's break it down in more practical terms.
1. grid-template-columns: Defining your layout
This property is used to set up the explicit grid — meaning, the columns you directly define in your CSS.
For example:
.grid {
display: grid;
grid-template-columns: 200px 1fr 2fr;
}This creates exactly three columns with the specified widths. Any grid item placed in these columns will follow their sizing rules.
? Use this when:
- You know how many columns you want upfront.
- You're defining a fixed or responsive layout manually.
- You're using named grid lines or areas.
If you place an item outside of these columns (like in a fourth column), the browser will automatically create new columns — and that’s where grid-auto-columns comes into play.
2. grid-auto-columns: Handling overflow columns
These columns are created automatically by the browser when there are more items than there are explicitly defined columns.
For instance:
.grid {
display: grid;
grid-template-columns: repeat(3, 100px);
grid-auto-columns: 50px;
}If you have more than three columns worth of content (say, you use grid-column: 4 on an item), the browser will create new columns that are 50px wide.
?? Common gotchas:
- If you don’t set
grid-auto-columns, the default width isauto, which can lead to unpredictable layouts. - This property is especially useful when using
grid-auto-flow: column, which allows items to flow horizontally into new columns.
So while grid-template-columns gives you control over the structure you plan for, grid-auto-columns helps manage what happens when things go beyond that.
3. When to use each (and why it matters)
You’ll typically use both together in more complex layouts, especially when dealing with dynamic content.
Use grid-template-columns when:
- You’re designing a known layout (e.g., a 3-column dashboard).
- You need precise control over specific columns.
Use grid-auto-columns when:
- You expect items to be added dynamically beyond the initial layout.
- You’re creating a horizontal scrolling grid layout.
- You want implicit columns to maintain consistent sizing.
They also work well with other properties like minmax() and auto-fit in repeat() for responsive behavior.
Final thoughts
Understanding the difference between grid-template-columns and grid-auto-columns boils down to knowing which columns are explicitly defined versus which ones are automatically generated. Once you get that distinction, it becomes much easier to control how your grid behaves under different scenarios.
That’s basically it — not too complicated once you see how they fit together.
