OAuth2 is responsible for authorization, and JWT is used to transmit information securely. The four roles of OAuth2 include resource owner, client, authentication server and resource server. The common process is the authorization code mode. After the user logs in, the client uses the code to exchange it for the token, and then uses the token to access the resources. JWT includes three parts: header, load and signature. The microservice confirms identity and resolves permission information by verifying the signature. Spring Boot integration uses the OAuth2 Resource Server module to configure issuer-uri and jwk-set-uri, and customizes permission parser extraction authorities. Notes include setting the token expiration time reasonably, refreshing the token with secure storage, correctly configuring CORS, and avoiding storing sensitive data in JWT.
OAuth2 and JWT are two core technologies that ensure the security of Java microservices. Simply put, OAuth2 provides an authorization mechanism, while JWT is used to securely transmit user information. They work together to enable flexible, scalable authentication and access control.

1. Basic roles and processes of OAuth2
In the microservice architecture, OAuth2 is mainly used to handle user authorization, and the four common roles include:
- Resource Owner : Usually a user.
- Client : The application that initiates the request, such as a front-end application or a mobile terminal.
- Authorization Server : Responsible for issuing tokens.
- Resource Server : A protected service, such as a Java microservice.
The most common process is Authorization Code Flow , which is suitable for applications with backends. The process is roughly as follows:

- User attempts to access protected resources
- Redirected to the authentication server to log in and authorize
- Get the authorization code (code)
- The client exchanges access tokens for authentication server using code
- Use access token to access the resource server
The core of this process is to "replace the token with code", which avoids direct exposure of the token.
2. The role of JWT in microservices
JWT (JSON Web Token) is a lightweight data exchange format that is often used for authentication. It contains three parts:

- Header: Instructions signature algorithm, etc.
- Payload: contains user information (such as username, permissions, etc.)
- Signature: Ensure that the data has not been tampered with
In Java microservices, the usual practice is:
- Authorization server generates a signature JWT
- Verify the signature validity of the JWT when the microservice receives a request
- Dissolve user information to determine whether you have permission to access
The advantages are obvious: stateless, suitable for distributed systems; disadvantages also exist, such as the inability to undo the token as easily as a session.
3. How to integrate OAuth2 JWT in Spring Boot
Spring Security provides good support for OAuth2 and JWT, and here is a common practice:
Using Spring Security OAuth2 Resource Server
If you already have an authentication server (such as Keycloak or self-built Spring Authorization Server), each Java microservice only needs to be used as a Resource Server to verify the token.
Key configuration steps include:
- Add dependencies:
spring-boot-starter-oauth2-resource-server
- Configure issuer-uri and jwk-set-uri in
application.yml
- Turn on method-level permission control (such as
@EnableMethodSecurity
)
spring: security: oauth2: resource-server: jwt: jwk-set-uri: https://your-auth-server/.well-known/jwks.json
This way, Spring automatically downloads the public key and verifies that the JWT carried by each request is legal.
Custom permission resolution (optional)
You can extract permission information in JWT by implementing JwtAuthenticationConverter
, for example:
JwtAuthenticationConverter jwtConverter = new JwtAuthenticationConverter(); jwtConverter.setJwtGrantedAuthoritiesConverter(jwt -> { List<String> authorities = jwt.getClaimAsStringList("authorities"); return authorities.stream() .map(SimpleGrantedAuthority::new) .collect(Collectors.toList()); });
Then set it into the Security configuration.
4. Frequently Asked Questions and Precautions
- The expiration time of tokens should not be too long : generally set to between a few minutes and a few hours to avoid long-term effectiveness after leakage.
- Refreshing a token requires careful handling : Refreshing a token should be stored more securely (such as HttpOnly Cookies) and limit its usage.
- Cross-domain requests require CORS : especially in front-end and back-end separation architecture, pay attention to cross-domain issues in the authentication process.
- Don't put sensitive information in JWT : Although signatures can prevent tampering, the content itself is plain-text-visible.
Basically that's it. By mastering the OAuth2 process and how to use JWT, the Java microservice security system can lay a solid foundation.
