Mapping a network drive allows you to access shared folders on another computer or server as if they were a local drive on your own machine. This is useful for accessing files on a home or office network. Here’s how to map a network drive on Windows and macOS.

On Windows (Windows 10 and Windows 11)

1. Open File Explorer
   Click the folder icon on the taskbar or press Windows E.

2. Go to "This PC"
   In the left-hand sidebar, click "This PC".



3. Map Network Drive

   • Click the "Computer" tab at the top (in older versions) or the "Home" tab, then look for "Map network drive".
   • In newer versions, click "More" (three dots) → "Map network drive".

4. Choose a Drive Letter
   Select a letter (e.g., Z:) from the dropdown. This will be the name of your mapped drive.



5. Enter the Network Path
   Type the path to the shared folder in the format:

   \\SERVERNAME\ShareName

   or

   \\IP_ADDRESS\SharedFolder

   For example: \\192.168.1.100\Documents

6. Reconnect at Sign-in (Optional)
   Check "Reconnect at sign-in" if you want the drive to appear every time you log in.

7. Connect Using Different Credentials (If Needed)
   If you don’t have permission, check "Connect using different credentials". You’ll be prompted to enter a username and password for the remote computer or server.

8. Click Finish
   The drive will appear under "This PC". If credentials are required, enter them when prompted.

Note: The remote computer must be turned on, sharing must be enabled, and the folder must be shared with your user account.

On macOS

macOS doesn’t use "drive letters", but you can mount a shared network folder on the desktop or in Finder.

1. Open Finder
   Click the Finder icon in the Dock.

2. Go to "Connect to Server"

   • From the menu bar, click Go → Connect to Server.
   • Or press Command K.

3. Enter the Server Address
   Use one of these formats:

   • For Windows/SMB shares: smb://SERVER_ADDRESS/ShareName Example: smb://192.168.1.100/Documents
   • For Mac/Apple sharing: afp://SERVER_ADDRESS/ShareName

4. Click Connect
   Then click "Connect" in the dialog.

5. Authenticate
   Enter your username and password for the remote machine. If it’s a Windows PC, use:

   DOMAIN\Username

   or

   COMPUTERNAME\Username

   Then enter the password.

6. Mount the Share
   After connecting, the shared folder will appear on your desktop and in the Finder sidebar.

Tip: To make it connect automatically, drag the mounted drive to the "Login Items" section in Users & Groups settings.

Troubleshooting Tips

• Ensure both computers are on the same network.
• File sharing and network discovery must be enabled on the host computer.
• Windows: Make sure "Network discovery" and "File and printer sharing" are turned on (via Network and Sharing Center).
• macOS: The remote machine must allow file sharing (System Settings → Sharing → File Sharing).
• Use IP addresses instead of names if the network doesn’t resolve hostnames properly.
• Antivirus or firewall settings may block file sharing—check if necessary.

Basically, mapping a network drive is straightforward once you know the correct path and have the right permissions. Just remember the format of the network address and your login details.
