MySQL data at rest encryption is mainly achieved through three steps: 1. Enable InnoDB tablespace encryption, configure my.cnf parameters such as innodb_encrypt_tables=ON and set the encryption algorithm AES-CBC, but the old table needs to be manually migrated; 2. Encrypt the data directory at the file system layer, use LUKS, eCryptfs or cloud services such as AWS EBS to encrypt the disk, overwrite logs and temporary files; 3. Implement key management policies and use external KMS such as AWS KMS or HashiCorp Vault to avoid key leakage, regularly rotate and separate the master key and table key, ensuring that even a single key leak does not affect overall security.
The encryption of MySQL data at rest is actually to encrypt and protect the data when it is not accessed, such as when it is stored on disk. This step is critical, especially when faced with loss of physical devices, unauthorized access, or compliance requirements. If your database has user information, transaction records or sensitive configurations, not encrypting it is equivalent to keeping the door open and waiting for others to come in.

The following aspects are what most people care about when setting up MySQL data at rest encryption. I will explain them one by one.
1. Enable InnoDB tablespace encryption
MySQL supports InnoDB's transparent data encryption (TDE) since 5.7, which means that you do not need to change the application code, you only need to open relevant options in the configuration file to achieve encryption.

The operation steps are roughly as follows:
- Make sure to use a version that supports encryption, such as MySQL Enterprise or Percona Server.
- Enable tablespace encryption in
my.cnf
:
[mysqld] innodb_encrypt_tables=ON innodb_encryption_threads=4
- Set the default encryption algorithm, such as AES-CBC:
innodb_default_encryption_key_id = 1 innodb_tablespaces_encryption = ON
Note: After turning on, all new tables will be automatically encrypted, but the old tables will not be automatically encrypted, and the tables need to be reconstructed manually or data can be migrated.

2. Encrypt data directory and file system layer
In addition to database-level encryption, operating system-level encryption is also a line of defense. If you are worried that the entire server disk will be stolen, you have to consider encrypting at the file system layer.
Commonly used solutions include:
- Encrypt the entire disk partition using LUKS (Linux Unified Key Setup).
- Use encrypted file systems such as eCryptfs or ZFS.
- Disk encryption features provided by cloud service providers, such as AWS EBS encrypted volumes.
The advantage of this method is that it is completely transparent to MySQL, does not affect too much performance, and can cover all data files, including logs, temporary files, and other places where InnoDB encryption may be missed.
However, one thing to note: Once the key is lost, the data will be completely gone, so you must be extra careful in key management.
3. Key management policies cannot be ignored
Whether it is InnoDB or file system encryption, key management is indispensable. This is the most prone place to go - where to put the key? How to rotate? How to backup?
Suggested practices:
- Use external key management services (KMS), such as AWS KMS, HashiCorp Vault.
- Do not write the key directly into the configuration file, as it is easy to leak.
- Rotate the keys regularly and make sure the old keys are still available to decrypt historical data.
- Store the master key and data separately to avoid "one key to unlock all locks".
For example, InnoDB supports the use of "master keys" and "table keys", each table has its own key, and the master key is used to encrypt these table keys. In this way, even if a certain table key is leaked, it will not affect all data.
Basically that's it. Encryption of data at rest seems simple, but when it is really time to implement, there are many details, especially in key management and compatibility. Don't underestimate this step, sometimes compliance audits are stuck here.
The above is the detailed content of Securing MySQL Data at Rest with Encryption. For more information, please follow other related articles on the PHP Chinese website!
