Use OpenCV to realize camera video capture, and read the default camera and display the screen in real time by creating VideoCapture objects; 2. You can set resolution, frame rate and other parameters to optimize video quality; 3. You can save the frames captured by the camera as a video file, and you need to ensure that the encoding format, resolution and frame size of VideoWriter matches the frame size; 4. Support reading local video files such as mp4 and avi formats and playback; 5. Notes include correctly setting waitKey to control playback speed, device number selection, system permissions and driver support issues. This example fully covers the core functions of video capture, display, save and playback in OpenCV, providing a foundation for subsequent expansion of face recognition, motion detection and other applications.
Here is a simple and practical example of video capture using Python and OpenCV for reading video streams from the camera and displaying them in real time.
? Basic video capture example (from the camera)
import cv2
# Create a VideoCapture object, 0 means the default camera cap = cv2.VideoCapture(0)
# Check whether the camera is successfully opened if not cap.isOpened():
print("Camera cannot be turned on")
exit()
While True:
# Capture ret frame by frame, frame = cap.read()
# If the frame is read correctly, ret is True
if not ret:
print("Cannot receive frames (maybe stream ended?), exit...")
break
# Show frame cv2.imshow('camera screen', frame)
# Press the 'q' key to exit if cv2.waitKey(1) == ord('q'):
break
# Release resource cap.release()
cv2.destroyAllWindows()? Common settings (resolution, frame rate, etc.)
You can set camera parameters before capturing:
cap = cv2.VideoCapture(0)
cap.set(cv2.CAP_PROP_FRAME_WIDTH, 640) # Set width cap.set(cv2.CAP_PROP_FRAME_HEIGHT, 480) # Set height cap.set(cv2.CAP_PROP_FPS, 30) # Set frame rate# Optional: Print the current set print(f"Resolution: {cap.get(cv2.CAP_PROP_FRAME_WIDTH)}x{cap.get(cv2.CAP_PROP_FRAME_HEIGHT)}")
print(f"FPS: {cap.get(cv2.CAP_PROP_FPS)}")? Save video to file
If you want to save the content captured by the camera into a video file:
import cv2
cap = cv2.VideoCapture(0)
fourcc = cv2.VideoWriter_fourcc(*'XVID') # Encoding format out = cv2.VideoWriter('output.avi', fourcc, 20.0, (640, 480))
While True:
ret, frame = cap.read()
if not ret:
break
out.write(frame) # Write frame cv2.imshow('Recording...', frame)
if cv2.waitKey(1) == ord('q'):
break
cap.release()
out.release()
cv2.destroyAllWindows()?? Note: When saving video, the resolution of
VideoWritermust be consistent with the size of the written frame.
? Read local video files
Not only the camera, OpenCV can also read video files such as .mp4 and .avi :
cap = cv2.VideoCapture('input.mp4') # Replace with your video path while cap.isOpened():
ret, frame = cap.read()
if not ret:
print("Video playback ends")
break
cv2.imshow('Video Play', frame)
if cv2.waitKey(25) == ord('q'): # waitKey controls playback speed break
cap.release()
cv2.destroyAllWindows()? Tips
-
cv2.waitKey(1): The parameter is milliseconds, indicating the display time per frame. The smaller the value, the faster the video. - Camera device number: If there are multiple cameras, you can try
1,2, etc. - Virtual Environment Issues: Some systems (such as macOS or Linux) may require additional drivers to support the camera.
- Permissions issue: Make sure the program has permission to access the camera (especially on Mac or browser sandbox environments).
Basically that's it. This example covers the most common usage scenarios for OpenCV video capture: real-time capture, display, save and play. You can expand the functions of facial recognition, motion detection and other functions based on this.
The above is the detailed content of python opencv video capture example. For more information, please follow other related articles on the PHP Chinese website!
