python seaborn jointplot example

Jul 26, 2025 am 08:11 AM
python seaborn

Use Seaborn's jointplot to quickly visualize the relationship and distribution between two variables; 2. The basic scatter plot is implemented by sns.jointplot(data=tips, x="total_bill", y="tip", kind="scatter"), the center is a scatter plot, and the histogram is displayed on the top and bottom and right sides; 3. Add regression lines and density information to use kind="reg" and combine marginal_kws to set the edge map style; 4. When the data volume is large, kind="hex" is recommended, and use hexagonal box plot to display data dense areas; 5. Use kind="kde" to combine fill=True and thresh=0.05 to draw the filled kernel density contour plot to clearly present the distribution trend; 6. Common parameters include data, x, y, kind, margin_kws, height and ratio. Jointplot is suitable for exploring the relationship and distribution of bicontinuous variables, with concise code and rich information.

python seaborn jointplot example

Using Seaborn's jointplot in Python can easily visualize the relationship between two variables while showing their respective distributions. Here is a practical jointplot example to help you get started quickly.

python seaborn jointplot example

1. Basic scatter plot jointplot (scatter)

 import seaborn as sns
import matplotlib.pyplot as plt

# Load sample data tips = sns.load_dataset("tips")

# Create jointplot
sns.jointplot(data=tips, x="total_bill", y="tip", kind="scatter")

plt.show()

This generates a scatter plot, with the center of the scatter relationship between total_bill and tip , and the top and right are the histograms of the two variables respectively.


2. Jointplot with regression lines and density maps

If you want to see trends and distribution density more clearly:

python seaborn jointplot example
 sns.jointplot(data=tips, x="total_bill", y="tip", kind="reg", marginal_kws=dict(bins=15, fill=True))

plt.show()
  • kind="reg" : Add regression line and correlation information.
  • marginal_kws : Controls the style of the edge diagram (upper and right), such as the number of columns and whether to fill in color.

3. Use hexagonal box plots (hex) to display large amounts of data

When there are many data points and the scatter plots overlap severely, hexagonal box plots can be used:

 # Generate some simulated data import numpy as np
np.random.seed(42)
x = np.random.randn(1000)
y = x np.random.randn(1000)

# Use hex mode sns.jointplot(x=x, y=y, kind="hex", color="blue")

plt.show()

The darker the hexagon color, the denser the data points in the area.

python seaborn jointplot example

4. Use kernel density estimation (kde) to display the distribution

 sns.jointplot(data=tips, x="total_bill", y="tip", kind="kde", fill=True, thresh=0.05)

plt.show()
  • kind="kde" : Use contour graph to represent density.
  • fill=True : Fill color.
  • thresh=0.05 : Set density threshold to avoid edge noise.

Common parameter description

  • data : DataFrame data.
  • x , y : variable name (string) or array.
  • kind : Drawing type, optionally "scatter" , "reg" , "resid" , "kde" , "hex" .
  • marginal_kws : controls the parameters of the edge graph.
  • height : image size (such as height=6 ).
  • ratio : The ratio of the center graph to the edge graph (default 5:1).

Basically these common uses. jointplot is suitable for exploring the relationship and distribution of two continuous variables. A few simple lines of code can obtain rich information.
