Linux uses the Filesystem Hierarchy Standard (FHS) to organize directories systematically, ensuring consistency across distributions; 2. Key directories include /bin for essential user binaries like ls and bash, critical for early boot; 3. /sbin contains system administration tools such as fdisk and iptables, typically used by root; 4. /usr holds user-facing software and resources in subdirectories like /usr/bin, /usr/sbin, /usr/lib, /usr/share, and /usr/local for locally compiled programs; 5. /etc stores system-wide configuration files such as /etc/passwd and /etc/fstab; 6. /var contains variable data including logs in /var/log, caches in /var/cache, spools in /var/spool, runtime data in /var/run (a symlink to /run), and application state in /var/lib; 7. /tmp is for temporary files cleared on reboot, while /var/tmp stores temporary data that may survive reboots; 8. /dev contains device files representing hardware like /dev/sda and special devices like /dev/null; 9. /proc and /sys are virtual filesystems providing kernel and hardware information through memory-mapped interfaces; 10. /home holds personal user directories with configurations and files, while /root is the dedicated home for the root user; 11. /run stores runtime data such as PID and socket files, mounted in memory for speed and cleared at reboot; 12. /boot contains bootloader files, kernel (vmlinuz), and initramfs needed before root filesystem mounts; 13. /lib and /lib64 store essential shared libraries required by /bin and /sbin for system boot; 14. /opt is for optional third-party software like Google Chrome, often self-contained in its own subdirectory; 15. /mnt is for temporary manual mounts, and /media for automatically mounted removable media like USB drives; understanding the FHS enables efficient system management, scripting, and troubleshooting by clarifying the purpose and location of each directory.

Linux doesn’t just throw files anywhere—it follows a well-defined structure called the Filesystem Hierarchy Standard (FHS). This standard ensures consistency across distributions, making it easier for admins, developers, and scripts to know where things should be. Whether you're troubleshooting, writing a script, or just trying to understand where logs go, knowing the FHS is essential.

Here’s a practical breakdown of the key directories and what they’re for.

/bin – Essential User Binaries

This is where fundamental command-line tools live—programs you absolutely need to get basic work done, even in single-user mode.

• Examples: ls, cp, mv, bash, grep
• These binaries are available early in the boot process.
• /bin is usually a symbolic link to /usr/bin on modern systems (thanks to the usrs merge).

? Why it matters: If your system boots without /usr, /bin must still work. That’s why only critical tools go here.

/sbin – System Administration Binaries

Like /bin, but for system-level commands—tools typically used by root or with elevated privileges.

• Examples: fdisk, iptables, reboot, ifconfig
• Not usually in a regular user’s PATH
• Often symlinked to /usr/sbin on newer systems

These are the tools that keep the system running, not the ones you use daily for file manipulation.

/usr – User Resources (but not just for users)

Despite the name, /usr isn’t for home directories. It’s a read-only hierarchy containing most of the system’s user-facing software and data.

Think of it as the "applications and shared resources" directory.

Subdirectories you’ll see:

• /usr/bin – Most user commands
• /usr/sbin – Non-essential system binaries (like httpd, sshd)
• /usr/lib – Libraries for /usr/bin and /usr/sbin
• /usr/share – Architecture-independent data (docs, icons, man pages)
• /usr/local – Locally compiled software (not managed by package manager)

? Fun fact: /usr used to mean "user" as in user-installed programs, but now it's more of a historical artifact. On many systems, /usr is mounted read-only.

/etc – Configuration Central

All system-wide configuration files live here. No binaries, no data—just config.

• /etc/passwd, /etc/fstab, /etc/ssh/sshd_config
• Host-specific: settings that don’t change when you swap drives or reinstall
• Package managers drop config files here during installation

?? Rule of thumb: If a program needs a system-wide setting, it’s probably in /etc.

/var – Variable Data

Files that change during system operation go here. Think logs, caches, spools, and transient data.

Common subdirectories:

• /var/log – Log files (e.g., syslog, auth.log)
• /var/cache – Cached data (e.g., package managers store .deb or .rpm files here)
• /var/spool – Queued tasks (print jobs, cron, mail)
• /var/run – Runtime variable data (often a symlink to /run)
• /var/lib – Persistent data for applications (e.g., databases, package managers)

? /var grows over time—this is often the partition you monitor for disk usage.

/tmp and /var/tmp – Temporary Files

Both are for temporary storage, but with differences:

• /tmp – Wiped on reboot (usually mounted as tmpfs in RAM)
• /var/tmp – Meant for files that survive reboots (but still not guaranteed long-term)

Permissions are tightly controlled—modern systems use sticky bits so users can’t delete each other’s temp files.

/dev – Device Files

Linux treats hardware as files. This directory contains device nodes that represent physical or virtual devices.

• /dev/sda – First SATA/SSD drive
• /dev/ttyUSB0 – USB-to-serial adapter
• /dev/null – Black hole (discards everything written to it)
• /dev/zero – Infinite source of zeros

Most of these are managed by udev dynamically as devices are detected.

/proc and /sys – Virtual Filesystems

These aren’t real files on disk. They’re interfaces to kernel data structures.

/proc – Process and system info

• /proc/cpuinfo, /proc/meminfo – Hardware details
• /proc/[PID] – Runtime info about running processes
• Originally for processes, now also used for system settings

/sys – Device and driver hierarchy (sysfs)

• Exposes kernel objects like devices, drivers, and class info
• Used for configuring hardware parameters at runtime
• Key for tools like udev

? Both are in memory (procfs and sysfs) and vanish when unmounted.

/home – User Home Directories

Each user gets a personal space here (e.g., /home/alice). Contains:

• Personal files (Documents, Downloads)
• Hidden config files (.bashrc, .ssh/)
• Usually not shared across machines (unlike /usr or /etc)

In enterprise setups, this might be on a network share (NFS).

/root – Home Directory for Root

Not /home/root. The root user’s home is directly under /root. Keeps it accessible even if /home is on a separate partition that fails to mount.

/run – Runtime Data

A relatively recent addition (replacing parts of /var/run). Stores transient files that need to persist only while the system is running.

• PID files (e.g., /run/sshd.pid)
• Lock files
• Socket files
• Mounted as tmpfs, so it’s fast and cleared on reboot

Ensures clean state on startup.

/boot – Bootloader and Kernel Files

Contains everything the system needs to boot before the root filesystem is available.

• /boot/vmlinuz – The kernel
• /boot/initramfs – Initial RAM disk
• /boot/grub/ or /boot/efi/ – Bootloader files

This can be a separate partition to ensure early boot components are accessible.

/lib and /lib64 – Essential Libraries

These hold shared libraries needed by /bin and /sbin.

• /lib – 32-bit libraries (even on 64-bit systems, for compatibility)
• /lib64 – 64-bit libraries on 64-bit systems
• Includes libc, ld-linux.so (the dynamic linker)

Like binaries in /bin, these are critical for early boot.

/opt – Optional Application Software

Used for installing third-party or proprietary software that doesn’t integrate with the standard hierarchy.

• Common for self-contained apps (e.g., Google Chrome, some Java apps)
• Each app typically lives in /opt/<appname></appname>
• Often includes its own bin, lib, etc under that directory

Less common now with containers and package managers, but still used.

/mnt and /media – Mount Points

• /mnt – Temporary manual mounts (e.g., mount /dev/sdb1 /mnt/backup)
• /media – Removable media (automatically mounted—USB drives, CDs)

Distros handle these differently, but both are just conventional places to attach filesystems.

Final Notes

The FHS isn’t just tradition—it’s practical. It helps:

• Automate system management
• Write portable scripts
• Troubleshoot faster
• Separate state from code

While some directories (like /bin → /usr/bin) have evolved due to the usrs merge, the logic remains: separation of concerns.

Understanding the FHS doesn’t require memorizing every path—but knowing the purpose behind each major directory makes Linux less mysterious.

Basically, if you know where to look, the system tells you how it works.
