To connect the Mac to the projector, you need to confirm the interface type and use the appropriate cable; 1. Confirm the Mac interface type (such as USB-C, HDMI, Mini DisplayPort) and prepare the corresponding adapter or cable; 2. Check whether the cable connection is stable, and manually switch the display output mode if necessary (Command F1 or select "Screen Mirror" through the control center); 3. Adjust the projector signal source input (such as HDMI 1 to HDMI 2); 4. Enter "System Settings" → "Display" to adjust the resolution and screen ratio, and try "Detected Resolution" or "Stretch" to obtain the best display effect; 5. If you need to expand the desktop instead of mirroring, drag the screen position in the "Display" setting to switch to the extended mode.
It is actually not difficult to connect a Mac to the projector, but if you are operating for the first time, you may get stuck in details such as interface type and setting order. This article will tell you how to successfully cast your Mac display content onto the large screen.

Confirm the interface type and cable
The interface between Mac and projectors may not be the same. Common ones include HDMI, VGA, and USB-C (thunderbolt port). Some old Macs may also use Mini DisplayPort. You need to first confirm your Mac interface type and which input method the projector supports.

For example:
- If you are using an M1 or a newer MacBook, it is likely that there is only a USB-C interface, and you need a USB-C to HDMI or VGA adapter.
- Older Macs may come with HDMI or Thunderbolt interfaces, which can be directly connected with the corresponding cable.
When buying wires or adapters, try to choose a brand with stable quality to avoid unstable signal or unrecognized problems.

Connect and switch display output
After plugging in, the Mac usually automatically recognizes the external monitor. If there is no response, you can try the following steps:
- Check if the cable is plugged in tightly, especially if the VGA or HDMI plug sometimes looks like it is plugged in, but it is not fully in place.
- Press Command F1 on your Mac (some models are Command F1 or need to be matched with the Fn key) to manually switch the display output mode.
- If you are using macOS Ventura or updated system, you can find the "Screen Mirror" option in the control center of the menu bar and select the corresponding output device.
Sometimes the projector itself also needs to manually switch the signal source, such as from "HDMI 1" to "HDMI 2", don't forget to see if the remote control or button has this setting.
Adjust resolution and display settings
The resolution of the projector is different from that of the computer. After direct connection, the picture may be blurred or stretched or deformed. At this time you can:
- Open System Settings → Monitor, press and hold Option and click Zoom. The "Detected Resolution" option will appear. You can try to switch to a resolution that is more suitable for the projector.
- If the screen proportion is incorrect, you can also adjust it to "default" or "stretch" modes here to see which one is the clearest.
Also, if you just want to expand the desktop instead of the mirrored screen, drag the screen position in the "Display" setting to switch to expansion mode.
Basically these steps. The whole process is not complicated, but you need to pay attention to the wire, interface matching and some small details, otherwise it is easy to get stuck on the problem of "connecting but not seeing the picture".
The above is the detailed content of How to connect a Mac to a projector. For more information, please follow other related articles on the PHP Chinese website!
