To customize the drag image in HTML5 drag and drop, use the setDragImage() method during the dragstart event. 1. Create or select an image element or hidden DOM element to serve as the custom drag image. 2. Call event.dataTransfer.setDragImage(element, offsetX, offsetY) within the dragstart listener, specifying the desired visual cue and its offset relative to the cursor. 3. For dynamic content, clone the draggable element, style it appropriately, append it to the DOM temporarily, and remove it after dragging ends using a timeout to ensure proper cleanup. This approach allows for cleaner visual feedback without relying on the default semi-transparent ghost image.
When you use HTML5 drag and drop, the default behavior shows a semi-transparent image of the element being dragged. But sometimes that’s not ideal — maybe it's too cluttered, or you want to give users a cleaner visual cue. The good news is, you can customize the drag image with just a bit of JavaScript.

How to Set a Custom Drag Image
HTML5 gives you access to the setDragImage()
method during the dragstart
event. This lets you specify a different element or even an offscreen image as the drag image.

Here’s how it works:
- You create an image element (or grab an existing one on the page).
- During
dragstart
, callevent.dataTransfer.setDragImage(imageElement, offsetX, offsetY)
.
The two offset values determine where the cursor appears relative to the image — usually set to something like 0,0 for top-left alignment, but you can tweak this depending on your UI needs.

For example:
const dragItem = document.querySelector('.draggable'); const customImage = new Image(); customImage.src = 'path/to/custom-drag-image.png'; dragItem.addEventListener('dragstart', function(event) { event.dataTransfer.setDragImage(customImage, 0, 0); });
This replaces the default ghost image with your own.
When to Use a Hidden Element as the Drag Image
Sometimes you don’t want to load an extra image file. In those cases, a common trick is to use a hidden DOM element as the drag image.
You can style a div to look like a simplified version of what you're dragging, hide it off-screen or inside a container with display: none
, then pass it into setDragImage
.
Here’s how:
- Create a styled element in your HTML.
- Hide it visually without removing it from the DOM.
- Reference it during
dragstart
.
This avoids extra HTTP requests and keeps everything inline. Just make sure the element isn't removed from the DOM when not visible — otherwise setDragImage
won’t work.
Handling Dynamic Content or Multiple Items
If you're dealing with dynamic content or multiple draggable items, you might need to generate the drag image on the fly.
One approach is to clone the element you're dragging and apply some styles to simplify its appearance. For example, remove borders, shadows, or child elements that add clutter.
You can do something like this:
dragItem.addEventListener('dragstart', function(event) { const clone = dragItem.cloneNode(true); clone.style.opacity = '0.5'; document.body.appendChild(clone); event.dataTransfer.setDragImage(clone, 10, 10); // Clean up after drag ends setTimeout(() => { document.body.removeChild(clone); }, 0); });
This way, each item gets a clean, consistent drag image without affecting the original element. The timeout ensures the clone stays around long enough to be used by the browser.
Final Notes
Customizing the drag image isn’t complicated, but it does require attention to timing and cleanup. Whether you go with a preloaded image, a hidden DOM element, or a dynamically generated clone, the key is making sure the drag image reflects the right state and doesn’t leave behind unnecessary nodes.
Also keep in mind that while setDragImage
is widely supported, some mobile browsers may handle drag visuals differently — so always test across platforms if touch interaction is important.
That’s about it. It’s not hard, but it’s easy to overlook small details like offsets or leftover elements.
